A network of resistors is connected to a 16 V battery with internal resistance of 1 Ω, as shown in the following figure. Compute the equivalent resistance of the network.
In the circuit shown in the figure, find the total resistance of the circuit and the current in the arm CD.
A cell of emf 4 V and internal resistance 1 W is connected to a d.c. source of 10 V through a resistor of 5 W. Calculate the terminal voltage across the cell during charging.
A 100 V battery is connected to the electric network as shown. If the power consumed in the 2 Ω resistor is 200 W, determine the power dissipated in the 5 Ω resistor.
Two cells of E.M.F. 10 V and 2 V and internal resistances 10 Ω and 5 Ω respectively, are connected in parallel as shown. Find the effective voltage across R.
A battery of emf 10 V and internal resistance 3 ohm is connected to a resistor. If the current in the circuit is 0.5 A, find :
(i) the resistance of the resistor;
(ii) the terminal voltage of the battery.
A network of resistors is connected to a 16 V battery with internal resistance of 1Ω as shown in the Fig. Compute the equivalent resistance of the network.
(a) 5 ohm
(b) 7 ohm
(c) 9 ohm
(d) 10 ohm
What is the amount of work done in moving a point charge around a circular arc of radius r at the center where another point charge is located ?
Why is choke coil needed in the use of fluorescent tubes with ac mains ?
The plot of the variation of potential difference across a combination of three identical cells in series, versus current is shown below. What is the emf and internal resistance of each cell ?
Graph showing the variation of current versus voltage for a material GaAs is shown in the figure, identify the region of :
The emf of a cell is always greater than its terminal voltage. Why ? Give reason.
For an ideal conductor, connected across a sinusoidal ac voltage source. State which one of the following quantity is zero :
(i) Instantaneous power
(ii) Average power over full cycle of the ac voltage source.
Plot a graph showing the variation of current I versus resistance R, connected to a cell of emf E and internal resistance r.
