Two point charges q and –2q are kept d distance apart. Find the location of the point relative to charge q at which potential due to this system of charges is zero.
Four point charges Q, q, Q and q are placed at the corners of a square of side ‘a’ as shown in the figure.
An electron is accelerated through a potential difference V. Write the expression for its final speed, if it was initially at rest.
A dielectric induces....... in an external electric field which decreases the net electric field.
(a) current
(b) dipole moment
(c) magnetic field
(d) polarisation
Four point charges –Q,-q,2q,2Q are placed at different corners of a square . The relation between Q and q for which the potential at the center of the square is zero
1.Q=q
2.Q=1/q
3.Q=-q
4. Q=-1/q
A charge ‘q’ is moved from a point A above a dipole of dipole moment ‘p’ to a point B below the dipole in equatorial plane without acceleration. Find the work done in the process.
Draw a plot showing the variation of (i) electric field (E) and (ii) electric potential (V) with distance r due to a point charge Q.
Two electric bulbs P and Q have their resistances in the ratio of 1 : 2. They are connected in series across a battery. Find the ratio of the power dissipation in these bulbs.
A 9 V battery is connected in series with a resistor. The terminal voltage is found to be 8 V. Current through the circuit is measured as 5 A. What is the internal resistance of the battery?
Calculate the current drawn from the battery by the network of resistors shown in the figure.
Using the concept of drift velocity of charge carriers in a conductor, deduce the relationship between current density and resistivity of the conductor.
A capacitor ‘C’, a variable resistor ‘R’ and a bulb ‘B’ are connected in series to the ac mains in circuit as shown. The bulb glows with some brightness.How will the glow of the bulb change if
(i) a dielectric slab is introduced between the plates of the capacitor, keeping resistance R to be the same;
(ii) the resistance R is increased keeping the same capacitance ?
Three concentric metallic shells A, B and C of radii a, b and c (a < b < c) have surface charge densities +σ, –σ and +σ respectively as shown in the figure.
Two cells of emf and have internal resistance and . Deduce an expression for equivalent emf of their parallel combination.
