A charge q is placed at one corner of the cube. The electric flux passing through any one of its face is
A point charge +Q is placed in the vicinity of a conducting surface. Draw the electric field lines between the surface and the charge.
Two charges of 2uC and 5uC are placed 2.5 cm apart. The ratio of Coulomb's force experienced by them is
Find the expression for electric field intensity in an axial position due to electric dipole.
Electric charge between two bodies can be produced by
(A )Sticking
(B) Rubbing
(C) Oiling
(D) Passing AC current
A current loop placed in a magnetic field behaves like a
a) Magnetic substance
b) Magnetic pole
c) Magnetic dipole
d) all true
\(10^6\) electrons are taken out of a pith ball. The positive charges on the pith ball is
A. 1.6x \(10^{-13}\) C
B. 1.6x \(10^{-19}\) C
C. 1.6x \(10^{-25}\) C
D. none of these
An electron initially at rest is accelerated through a potential difference of one volt. The energy gained by electron is:
(a) 1 J
(b) 1.6 × \(10^{-19}\) J
(c) \(10^{-19}\) J
(d) None of these
In a Young’s double slit experiment, the separation between the slits is 0.1 mm, the wavelength of light used is 600 nm and the interference pattern is observed on a screen 1 m away. Find the separation between bright fringes.
(A) 6.0 mm
(B) 6.6 mm
(C) 6 m
(D) 60 cm
The magnetic flux linked with a coil is given by an equation Φ = 5t² + 2t + 3. The induced e.m.f. in the coil at the third second will be
(A) 32 units
(B) 54 units
(C) 40 units
(D) 65 units
In YDSE, The distance between two consecutive bright and dark fringes are given by:
(a) β=λD/d
(b) β=λd/D
(c) β=λDd
(d) β=λ/Dd
In series R-L-C circuit, quality factor can be improved by
(a) decreasing L
(b) increasing C
(c) decreasing R
(d) decreasing R & L
