A. 1:1
Two-point charges 2μC and 4μC are placed 2 cm apart. The ratio of the Coulomb’s force experienced by them is
(A) 1: 2
(B) 2: 1
(C) 1: 1
(D) 4: 1
A charge q is placed at one corner of the cube. The electric flux passing through any one of its face is
Find the expression for electric field intensity in an axial position due to electric dipole.
When a body charges by conduction, its mass
(A) Remains same
(B) Increases
(C)Decreases
(D)Increase or decrease
what is the angle between an electric dipole moment and then electric field strength due to it on its equatorial line?
(A) \(0^\circ\)
(B) \(90^\circ\)
(C) \(180^\circ\)
(D) None of these
A conducting rod of unit length moves with a velocity 10 m/s in a direction perpendicular to its length and perpendicular to a uniform magnetic field of magnitude 0.2 T. The emf induced between the ends of the rod is
(a) 4 V
(b) 2V
(c) 1V
(d) Zero
A single slit diffraction pattern is obtained using a beam of red light What happened if the red light is replaced by the blue light?
(a) There is no change in diffraction pattern
(b) Diffraction fringes become narrower and crowded
(c) Diffraction fringes become broader and farther apart
(d) The diffraction pattern disappear
To observe diffraction, the size of the obstacle
(a) should beX/2, where X is the wavelength.
(b) should be of the order of wavelength.
(c) has no relation to wavelength.
(d) should be much larger than the wavelength.
A deuteron of kinetic energy 50 keV is describing a circular orbits of radius 0.5 m in a plane perpendicular to the magnetic field B . The kinetic energy of the proton that describes a circular orbit of same radius and inside same B is-
(a) 25 kev
(b) 50 kev
(c) 200 kev
(d) 100 keV
A 40 mF capacitor is connected to a 200 V, 50 Hz ac supply. The r.m.s value of the current in the circuit is, nearly
(a) 1.7 A
(b) 2.05 A
(c) 2.5 A
(d) 25.1 A
Two currents loops are concentric and lie in the same plane. The current in the outer loop is anti clockwise and increasing with time. The induced current in the inner loop ,is
(a) Clockwise
(b) Zero
(c) Counter-clockwise
(d) None of these
